Kernel Engineering Workshop · Lecture 1
How fast can this go?
What happens inside a GPU when you ask a chatbot a question, and the speed limit on every GPU program.
Dr. Raj Dandekar · Vizuara AI Labs
So what?
Almost all of it is matrix multiplication
36 blocks × (42 M + 151 M) weights
+ the output layer 622 M
= 7.57 billion multiply-adds for every token
Qwen3-8B, from its configuration: hidden size 4,096, feed-forward size 12,288, 36 blocks, 151,936-word vocabulary.
How fast can a GPU go?
The H100's ceiling, from its parts
132 SMs × 4 tensor cores × 1,024 operations per tick
× 1.83 billion ticks a second
= 989 trillion operations a second
Dense BF16 on the H100 SXM5 (NVIDIA datasheet). We call it 989 TFLOP/s.
If we could use all of it
One token would take 15 microseconds
15.2 billion operations ÷ 989 trillion a second
= 15 µs a token = 65,000 tokens a second
A 300-page book is about 130,000 tokens: at this speed, 2 seconds.
Reality
Measured on our H100: 149 tokens a second
149 tokens a second, measured
the same book: 14 minutes
we are using 0.23% of the GPU
Measured on a Modal H100, 28 September 2026: Qwen3-8B in BF16 served by vLLM, one user.
Physics sets the limit
The weights cannot fit next to the math
| what | value | source |
|---|---|---|
| fast memory on the H100 chip | 116 MB | 50 MB L2 + registers + shared memory |
| the model's weights read per word | 15.1 GB | Qwen3-8B, BF16 |
| SRAM area for those weights | 3,000 mm² | TSMC 2 nm SRAM, 38.1 Mb/mm² |
| largest printable chip | 858 mm² | lithography reticle, 26 × 33 mm |
| energy: read 32 bits from DRAM | 640 pJ | Horowitz, ISSCC 2014 |
| energy: one 32-bit multiply | 3.7 pJ | Horowitz, ISSCC 2014 |
The one equation
Bandwidth times math per byte
operations per second = bandwidth × operations per byte
(while memory is the limit)
Bandwidth is fixed by the hardware: 3.35 TB/s on the H100. Operations per byte is ours: it depends on how the work is organised, which is what kernels, batching and precision change.
One step, one user
The step takes the longer of the two
memory time = 15.1 GB ÷ 3.35 TB/s = 4.5 ms
compute time = 15.2 G ÷ 989 T = 0.015 ms
step = the longer = 4.5 ms measured: 6.7 ms
The gap between 4.5 ms on paper and 6.7 ms measured is what kernel engineering closes.
One user in numbers
About one operation per byte
operations per byte = 15.2 G ÷ 15.1 GB ≈ 1
3.35 TB/s × 1 = 3.35 TFLOP/s at best: 0.34% of 989
measured: 2.3 TFLOP/s = 0.23% of the GPU
Same bytes, more math
Operations per byte grow with users
| users | operations per byte | GPU share on paper | measured, tokens/s | GPU share measured |
|---|---|---|---|---|
| 1 | 1 | 0.34% | 148 | 0.23% |
| 64 | 60 | 20% | 8,006 | 12% |
| 256 | 195 | 66% | 20,818 | 32% |
| 1,024 | 452 | 100% | 26,303 | 40% |
Measured on a Modal H100 through the live server, 28 September 2026 (128 tokens of conversation per user). Past 295 operations per byte the chip is compute-bound.
Before the project
The recipe
- Count the operations.
- Count the bytes.
- Divide: operations per byte.
- Compare with the ridge, 295: which roof holds you down?
- Predict the time: the longer of memory and compute.
- Measure, and explain the gap.
Hour 2 · the project
The class is the batch
Qwen3-8B on one H100 on Modal, served with vLLM. One H100 costs about $3.95 an hour. How many of you can it serve at once, and what does each answer cost?
Students
phones and laptops
→
Class page
on Modal, a class code
→
vLLM on one H100
Qwen3-8B, BF16
→
Live roofline
users, tokens a second, cost
probe.py · chat.py · dashboard.py · loadgen.py · loadwatch.py
Predict first
Write your numbers before we run anything
| users | memory time | compute time | limit | each user, tok/s | together, tok/s | your guess |
|---|---|---|---|---|---|---|
| 1 | 4.52 ms | 0.02 ms | memory | 221 | 221 | ? |
| 8 | 4.56 ms | 0.12 ms | memory | 219 | 1,753 | ? |
| 64 | 4.88 ms | 0.98 ms | memory | 205 | 13,117 | ? |
| 256 | 5.96 ms | 3.94 ms | memory | 168 | 42,947 | ? |
| 512 | 7.40 ms | 7.87 ms | compute | 127 | 65,042 | ? |
| 1,024 | 10.29 ms | 15.74 ms | compute | 64 | 65,042 | ? |
Per step on paper: memory time = (15.1 GB + users × 128 tokens × 144 KiB) ÷ 3.35 TB/s; compute time = users × 15.2 billion operations ÷ 989 TFLOP/s. The step takes the longer one.
Your turn
Everyone, send a prompt on 3, 2, 1
Open the class page, type the class code, and ask the chatbot anything. Then watch the dot move to the right.
vizuaraai--l1-dashboard-web.modal.run
class code
roofline
Rehearsal run
What the H100 actually did
| users | step | each user, tok/s | together, tok/s | per million tokens |
|---|---|---|---|---|
| 1 | 6.69 ms | 149 | 148 | $7.40 |
| 64 | 7.79 ms | 128 | 8,006 | $0.137 |
| 256 | 11.92 ms | 84 | 20,818 | $0.053 |
| 512 | 20.29 ms | 49 | 24,631 | $0.045 |
| 1,024 | 37.77 ms | 26 | 26,303 | $0.042 |
Measured on a Modal H100 through the live server and simulated users, 28 September 2026: Qwen3-8B in BF16, vLLM, 64-token prompts and 128-token answers.
What an answer costs
Same GPU, 177 times cheaper per token
cost per million tokens = $1,097 ÷ tokens per second
because the H100 bills $0.001097 a second on Modal.
1 user, 148 tokens a second
$7.40
1,024 users, 26,303 tokens a second
$0.042
Before Lecture 2
Your assignment: the napkin audit
- Pick a 7B LLM. For its four op families (QKV projections, attention matmuls, MLP matmuls, elementwise and norm ops), compute the operations per byte at decode (batch 1, one token) and at prefill (2,048 tokens).
- Place all eight dots on one hand-drawn H100 roofline and label each memory-bound or compute-bound.
- Predict two families' speed, then measure them with the lab's timing harness. One page: the drawing, the dots, the two measurements, and your biggest surprise.
Next: Lecture 2, the CUDA programming model. How a GPU actually runs your code.
